ACO3000
Product Code: ACO3000
Rating: Be the first to write a review
Weight: 8001.0g
Product Condition: New
- Intel® 5th Core™ processor i5-5350U, up to 2.9GHz / i3-5010U, 2.1GHz or Celeron® 3765U, 1.9GHz
- Triple Independent Display
- Support up to 6x LAN or 4x PoE by Unique Modular Design
- Multiple Expansion Capability including PCIe, PCI, and Mini PCIe
- Wide Operating Temperature (-40°C to 70°C)
- 9 to 48 VDC Wide Range Power Input Supporting AT/ATX Mode
- Power Ignition Management
|
| Vehicle Applied Fanless System based on Intel® Broadwell-U processors |
| Model | ACO-3000 |
| CPU Onboard | Intel® 5th Gen. Core™ i5-5350U, i3-5010U, Celeron® 3765U |
| Memory | 1x 204-pin DDR3L-1333/1600MHz SO-DIMM, up to 8GB |
| Graphic Output | 1x DVI-I, 1x DisplayPort |
| LAN | 2x GbE RJ45 (Support Wake-on-LAN and PXE) |
| USB, Serial, & Digital I/O | 4x RS-232/422/485, 2x USB 3.0, 2x USB 2.0, 8x isolated digital I/O |
|
Storage | 2x 2.5” SATA HDD Bay (1x internal, 1x removable) with RAID 0, 1, 5, 10 support, and 2x mSATA (shared by 2x Mini PCIe) |
| Internal Expansion Slot | 2x Full-size mini-PCIe (shared with mSATA) |
| Power | 9-48 VDC, AT/ATX Select, 3-pin Terminal Block |
| Ignition Management | Delay On/Off, Battery Level Monitoring |
| Audio | Speaker-out / Mic-in Phone Jack |
| Operating Temperature | -40 °C to 70 °C |
| Certification | E-Mark, EMC Conformity with EN50155 & EN50121-3-2 |
| Dimensions (WxDxH) | 185 x 197 x 57.4 mm |
| Weight | 2.16 - 2.54 kg |
| Universal Expansion Slot (front) | 1 |
|
Proprietary Module Expansion | Up to 1x Module • DTB-4LAN • DTB-4LAN-PWR • DTB-4LAN-M12 • DTB-4LAN-PWR-M12 |
